KSB RPH - Page 59

Bearing bracket Pump size
Part description
Volute casing Casing cover, uncooled Casing cover, cooled Shaft Impeller Impeller hub cap Angular contact ball bearing Cylindrical roller bearing Bearing bracket Bearing cover, pump end Bearing cover, motor end Joint ring Mechanical seal Seal cover Casing wear ring, suction side Casing wear ring, discharge side Impeller wear ring, suction side Impeller, discharge side Thrower, pump end Thrower, motor end Oil thrower Throttling bush Impeller screw Impeller nut
Part No.
102 161 210 230 260 320.02 322.01 330 360.01 360.02 411.10 433 471.01 502.01 502.02 503.01 503.02 507.01 507.02 508.01 542.01 906 922.01
250-630 39 34 34 6 39 1 4 4 4 4 4 8 4 4 21 22 21 22 4 4 4 6 1 -
250-710 40 35 35 6 40 1 4 4 4 4 4 9 4 4 23 24 23 24 4 4 4 6 1 -
300-630 43 36 36 6 43 1 4 4 4 4 4 9 4 4 27 28 27 28 4 4 4 6 1 -
350-400 44 37 37 7 44 1 4 4 4 4 4 7 4 4 29 30 27 31 4 4 4 6 1 -
350-500 45 38 38 6 45 1 4 4 4 4 4 9 4 4 29 29 27 27 4 4 4 6 1 -
350-630 46 36 36 6 46 1 4 4 4 4 4 8 4 4 32 32 33 33 4 4 4 6 1 -
B07 350-710 47 37 37 8 47 1 5 5 5 5 5 10 5 5 34 34 35 35 5 5 5 7 1 -
400-504 48 38 38 8 48 1 5 5 5 5 5 11 5 5 34 34 35 35 5 5 5 7 1 -
400-506 49 38 38 8 49 1 5 5 5 5 5 11 5 5 36 36 37 37 5 5 5 7 1 -
400-710 50 37 37 8 50 1 5 5 5 5 5 10 5 5 38 39 37 40 5 5 5 7 1 -
