4.3.1 System setting
① Working mode
After completing the setup of peak load shifting mode, the time for charging and discharging also
needs to be set.
--W O R K E MO DE --
1 : S EL F CO N S U M E
→
2 : P EA K SF T
3 : B AT P RI OR I T Y
--SYS SETTING--
→1:WORK MODE
2:PV INPUT
3:ZERO EXPORT
4:DRM ENABLE
5:EPS ENABLE
6:REMOTE CTRL
7:START DELAY
Time setup
② Input mode
CHA STAR1: 00:00
CHA REND1: 00:00
DIS START1: 00:00
DISC END1: 00:00
CHA STAR2: 00:00
CHA REND2: 00:00
DIS START2: 00:00
DISC END2: 00:00
→1:INDEPENDANT
2:PARALLEL
3:CV
This interface is used to access system
information.
Press UP/DOWN button to move corresponding
options.
Press ENTER to enter the selected menu.
Press ESC button to return to the setting interface.
There are 7 options in total, including working
mode, PV input type, anti-reflux enable, DRM
enable , EPS enable, remote controlled enable ,
boot delay time.（see from 1 to 7）
This interface is used to opt for the working mode.
After selecting the three modes, the restart
interface will be entered.
Press ESC button to return to setting interface.
This interface is used to set the time-1 of peak load
shifting.
Press UP/DOWN button to change the value.
Press ENTER to confirm.
Press ESC button to return.
This interface is used to set the time-2 of peak load
shifting.
Press UP/DOWN button to change the value.
Press ENTER to confirm.
Press ESC button to return.
Setup of PV Input mode.
The factory setting by default is standalone mode.
When parallel input is set to be stand-alone mode,
PV power will be imbalanced.
39
www.kstar.com
40
www.kstar.com
Interface
Description
Interface
Description
Interface
Description
Interface
Description
ZERO EXPORT -- --
→1:DISABLE
2:ENABLE
③ZERO EXPORT
Interface
Description
Default option is disabling.
Back-flow-prevention function.
--INPUT MODE --
User Manual User Manual
8:CEI SPI Ctrl
9:GFCI Enb
10:DISC MODE
