KStar BluE-S 5000D - System Introduction and Overview; System Configurations

Figure1 DC-coupled Storage System – Scheme
Figure 3 Hybrid-coupled Storage System – Scheme
Introduction
01
Kstar BluE-H5 (incl.BluE-PACK10.2 and BluE-S 5000D)/BluE-H3 (incl. BluE-PACK5.1
and BluE-S 3680D) can be applied in DC-coupled systems (mostly new installation),
AC-coupled systems (mostly retrofit) and Hybrid-coupled systems (mostly retrofit, and
PV capacity-increase), as the following schemes show:
User Manual User Manual
01
www.kstar.com
02
www.kstar.com
GridGrid Meter
Backup Loads
BluE-H5/H3
LAN
Monitoring
Device
PV
Normal Loads
CT
Figure 2 AC-coupled Storage System – Scheme
CAUTION:
If CT test pass but inverter still can't achieve export power
(power is not controllable or always 0 power output).
Please check installation location of the CT.
1.1 System Introduction
BluE H3-5
BluE H3-10
BluE H5-10
BluE H5-20
BluE-S 3680D
BluE-S 3680D
BluE-S 5000D
BluE-S 5000D
BluE-PACK5.1
BluE-PACK10.2
BluE-PACK10.2
BluE-PACK20.4
Inverter
ESS
Solution
Configuration
PV
PV
Monitoring
Device
LAN
BluE-H5/H3
PV Inverter
Grid Meter Grid
Backup Loads
Normal Loads
CT
GridGrid Meter
Backup Loads
BluE-H5/H3
LAN
PV Inverter
PV
Monitoring
Device
Normal Loads
CT
