User Manual User Manual
Threshold setting value: The value set by upper
computer software.
Threshold setting trip time: The trip time set by
upper computer software.
Threshold auto test value: The value of threshold
during coincidence between the threshold and
current measured value.
Threshold auto test trip time: The time from the
coincidence between the threshold and current
to the trip signal of disconnection switch.
Current measured voltage or frequency value:
The measurement value of grid voltage or
frequency during the coincidence.
Interface
Description
Set:253.0V 603s
Tes:253.0V 603s
Cur:230.0V Pass!
VACMAX(S1)
Set:264.0V 190ms
Tes:264.0V 188ms
Cur:230.0V Pass!
VACMAX(S2)
Threshold setting value: The value set by upper
computer software.
Threshold setting trip time: The trip time set by
upper computer software.
Threshold auto test value: The value of threshold
during coincidence between the threshold and
current measured value.
Threshold auto test trip time: The time from the
coincidence between the threshold and current
to the trip signal of disconnection switch.
Current measured voltage or frequency value:
The measurement value of grid voltage or
frequency during the coincidence.
Interface
Description
Set:195.0V 1.52s
Tes:195.0V 1.50s
Cur:230.0V Pass!
VACMIN
Threshold setting value: The value set by upper
computer software.
Threshold setting trip time: The trip time set by
upper computer software.
Threshold auto test value: The value of threshold
during coincidence between the threshold and
current measured value.
Threshold auto test trip time: The time from the
coincidence between the threshold and current
to the trip signal of disconnection switch.
Current measured voltage or frequency value:
The measurement value of grid voltage or
frequency during the coincidence.
Interface
Description
Set:50.2Hz 100ms
Tes:50.2Hz 94ms
Cur:49.9Hz Pass!
FACMAX(S1)
Set:51.5Hz 100ms
Tes:51.5Hz 94ms
Cur:49.9Hz Pass!
FACMAX(S2)
Threshold setting value: The value set by upper
computer software.
Threshold setting trip time: The trip time set by
upper computer software.
Threshold auto test value: The value of threshold
during coincidence between the threshold and
current measured value.
Threshold auto test trip time: The time from the
coincidence between the threshold and current
to the trip signal of disconnection switch.
Current measured voltage or frequency value:
The measurement value of grid voltage or
frequency during the coincidence.
Interface
Description
Set:47.5Hz 100ms
Tes:47.5Hz 94ms
Cur:49.9Hz Pass!
Set:49.8Hz 100ms
Tes:49.8Hz 97ms
Cur:49.9Hz Pass!
FACMIN(S1)
FACMIN(S2)
--IN UIREQ --
→1:INV MO DULE
2:MODULE SN
3:FIRMW ARE
4:RECORD
Press UP/DOWN button to move corresponding
options;
Press Enter button to jump to the selected menu;
Press ESC button to return to user interface;
There are four alternative options: machine
model，serial number，firmware version and
running records (refer to 1 to 4).
① Machine model
--INVERTER--
BluE H3-5
This interface displays machine model of the
inverter;
Press ESC button to return to inquiry interface.
Interface
Description
Interface
Description
4.4 Inquiry
