KStar BluE-S 5000D - Statistics

59
www.kstar.com
60
www.kstar.com
User Manual User Manual
③ Firmware Version
--FIRMWARE--
ARM VER:1.0.0
DSP VER:1.0.0
④ Running records
--STAT--
→1:TIME STAT.
2:CONNE. TIMES
3:PEAK POWER
4:E-TODAY
5:E-MONTH
6:E-TEAR
7:E-TOTAL
--REC (170)--
1:F10-1
DATE: 2018
-
12-01
TIME: 00 ：01：02
This interface displays firmware version for ARM
and DSP of the inverter;
Press ESC button to return to inquiry interface.
SN of the fault: Fault warning codes (500 at
utmost)(the latest fault or alarm marked as No.1)
Time of the fault:
Press UP/DOWN button to view the record;
Press ENTER button to enter the description
interface for corresponding records;
Press ESC button to return to Inquiry interface.
This interface is used to select statistics items;
Press UP/DOWN button to move corresponding
options;
Press Enter to enter the selected menu;
Press ESC button to return to user interface;
There are eight alternative options in total: time
accounting，grid-connection frequency/ peak
power/ power generation for the day / power
generation for the month/ power generation for the
year/gross power generation (refer to 1 to8).
① Time accounting
② Grid-connection frequency
-Time-
RUN: 5
GRID:
0
UNIT:
HOUR
-- CONNE.TIMES --
TIMES: 0
Operation length of inverter（hours）
Grid-connection length（hours）
Press ESC button to return to statistics interface.
This interface displays grid-connection
frequency of the inverter；
Press ESC button to return to statistics interface.
Interface
Description
Interface
Description
Interface
Description
Interface
Description
Interface
Description
③ Peak power
④
The day
--PEAK POWER--
HISTORY: 5000
TODAY:
0
UNIT:
W
This interface displays power peak in history and
for the day.
Press ESC button to return to statistics interface.
This interface displays power generation for the
day（kWh）;
PV power generation;
Electric energy selling to grid;
Electric energy buying from grid;
Power consumption of load;
Interface
Description
Interface
Description
4.5 Statistics
② Serial number
SN:
123456789532625
This interface displays serial number of the
inverter;
Press ESC button to return to inquiry interface.
Interface
Description
--E-TODAY--
PV: 0.0KWH
METER: 0.0KWH
GRID: 0.0KWH
LOAD: 0.0KWH
-SERIAL NUMBER-
