12xφ8*60
12xM6 Gasket
1x Battery Communication Cable
4xPower Cable
(2 black, 2 red)
6x M5*12
3x Mounting Panel
16xφ8*60
16x M6 Gasket
1xBattery Communication Cable
6x Power Cable
(3 black, 3 red)
8xM5*12
4xMounting Panel
09
www.kstar.com
10
www.kstar.com
BluE-PACK15.3
(includ three pieces BluE-PACK5.1)
BluE-PACK20.4
(includ four pieces BluE-PACK5.1)
8xφ8*60
8xM6 Gasket
1x Battery Communication Cable
2xPower Cable(1 black, 1 red)
4xM5*12
2xMounting Panel
BluE-PACK10.2
(includ two pieces BluE-PACK5.1)
4xφ8*60
4xM6 Gasket2xM5*12
1x Mounting Panel
BluE-PACK5.1
