KStar E8KT - 2.5 COMM Port Connections; 2.6 METER+DRY Port Connections; 2.7 Generator connections

Pin Pin
1
5
2
4
Description Description
6
3
DRY contact
DRY contact
GND
Input signal
RS485-B
RS485-A
PIN6
PIN5
Note:The CT arrow points to GRID.
When using the generator, user can refer to the following connection methods.
Pin
Pin
1
4
2
3
Description Description
GND
+5V
RS485-A
RS485-B
Note:
1.The Smart Meter(ADW300W or SDM630MCT are suggested.) with CT is already configured;
please do not change any settings on the Smart Meter.
2.One Smart Meter can be used with only one inverter.
3.three CTs must be used for one Smart Meter and must be connected on the same phase
with the Smart Meter power cable.
Smart Meter & CT connection diagram
METER+DRY port
6
5
2
3
33
34
User Manual User Manual
2.7 Generator connections
