34
 Switch ON the external battery switch of each UPS. Check if the charging current
displayed in LCD is normal.
Note!
The UPS cannot be parallel until each single unit is normal.
4.3 The Display
4.3.1 Datas: Displays the flow state of UPS work, and quickly enters real-time data by
clicking on the block.
Power rate
500kVA
Setting mode Date/time
Current fault
and event
log in
Logo
Home page
Operation status
Data page
Item
