KStar HIP3300E - Power Cable Connection; Battery Connection

23
Output circuit breaker
500A 3P
Battery circuit breaker
1000A 3P
400k
Mains input circuit breaker
800A 3P
Bypass input circuit breaker
630A 3P
Output circuit breaker
630A 3P
Battery circuit breaker
1250A 3P
500k
Mains input circuit breaker
1000A 3P
Bypass input circuit breaker
800A 3P
Output circuit breaker
800A 3P
Battery circuit breaker
1600A 3P
600k
Mains input circuit breaker
1250A 3P
Bypass input circuit breaker
1000A 3P
Output circuit breaker
1000A 3P
Battery circuit breaker
2000A 3P
800k
Mains input circuit breaker
1600A 3P
Bypass input circuit breaker
1250A 3P
Output circuit breaker
1250A 3P
Battery circuit breaker
2500A 3P
1000k
Mains input circuit breaker
2000A 3P
Bypass input circuit breaker
1600A 3P
Output circuit breaker
1600A 3P
Battery circuit breaker
3200A 3P
1200k
Mains input circuit breaker
2500A 3P
Bypass input circuit breaker
2000A 3P
Output circuit breaker
2000A 3P
Battery circuit breaker
4000A 3P
CAUTION!
Protective earth cable: Connect each cabinet to the main ground system. For
Grounding connection, follow the shortest route possible.
WARNING!
FAILURE TO FOLLOW ADEQUATE EARTHING PROCEDURES MAY
RESULT IN ELECTROMAGNETIC INTERFERENCE OR IN HAZARDS
INVOLVING ELECTRIC SHOCK AND FIRE
3.6 Power cable connect
Before equipment has been installed, must comfirm the input source type, common input or Split
input, if the input source is dual input, must remove the copper bar that connected bypass and mains.
