KStar HIP3300E - Circuit Breaker Recommendations

22
Battery input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Output
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
35N•m
1200k
Mains input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Bypass input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Battery input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Output
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
35N•m
3.6.3 Recommended input front-end and output back-end circuit breakers
UPS capacity
Component Specifications
100k
Mains input circuit breaker
200A 3P
Bypass input circuit breaker
200A 3P
Output circuit breaker r
200A 3P
Battery circuit breaker
320A 3P
120k
Mains input circuit breaker
250A 3P
Bypass input circuit breaker
250A 3P
Output circuit breaker
250A 3P
Battery circuit breaker
400A 3P
150K&160k
Mains input circuit breaker
320A 3P
Bypass input circuit breaker
320A 3P
Output circuit breaker
320A 3P
Battery circuit breaker
500A 3P
200k
Mains input circuit breaker
400A 3P
Bypass input circuit breaker
400A 3P
Output circuit breaker
400A 3P
Battery circuit breaker
630A 3P
250k
Mains input circuit breaker
500A 3P
Bypass input circuit breaker
500A 3P
Output circuit breaker
500A 3P
Battery circuit breaker
800A 3P
300k
Mains input circuit breaker
500A 3P
Bypass input circuit breaker
500A 3P
