21
Output
connector
Crimped OT
terminals
M12 13.5mm
26N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
26N•m
400k
Mains input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Bypass input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Battery input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Output
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
35N•m
500k
Mains input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Bypass input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Battery input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Output
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
35N•m
600k
Mains input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Bypass input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Battery input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Output
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
35N•m
800k
Mains input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Bypass input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Battery input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Output
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Grounding
connector
Crimped OT
terminals
M12 13.5mm
35N•m
1000k
Mains input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
Bypass input
connector
Crimped OT
terminals
M12 13.5mm
35N•m
