KStar KSH-3.68k-48 User Manual

21
8.1.12 Temperature
8.1.13 Status information
8.1.14 Error information
Interface
8.1.15 System setting
Interface Description
Interface
Interface
Interface Description
System information
：
Power-up mode,
standby mode, hybrid grid-connection,
off-grid operation, mains charging mode, PV
charging mode, bypass mode, fault mode,
DSP programming, ARM programming
INV: standby mode, off-grid inverter mode,
grid-connected mode, and transition of grid-connection
to off-grid, transition of off-grid to grid mode
DCDC: standby mode, soft start mode, charging mode,
discharging mode
POWER
PV I/P：W
LOAD： W
BAT： W
PV real-time total power
BACKUP real-time load
Battery real-time load（+ means discharge, -
means charge）
Real-time temperature of inverter system radiator
Real-time temperature ofBidirectional DCDC
System Radiator
Internal tem
p
erature of chassis
TEMPERATURE
INVER： 25℃
DCDC：26℃
INSIDE：27℃
SATE
SYS： ERROR
INV： STANDBY
DCDC： STANDBY
Alarm code（ see Chapter 9）
Error code（see Chapter 9）
ERROR NO.
WA RN IN G ： W11-1
FAULT： F10-1
