KStar KSH-3.68k-48 User Manual

41
INV Under
Volt
W18
(1) Wait five minutes for the inverter to
automatically restart;
(2) Check whether the load is in compliance with
the specification;
(3) Contact customer service if error warning
continues.
INV Over
Volt
W19 (1) Please contact the distributor.
INV
Frequency
Loss
W20 (1) Please contact the distributor.
11. Machine Parameters
Model KSH-3.68k-48 KSE-4.6k-48 KSH-5k-48
DC input
Maximum PV input
power
4600w/2300w 5600w/2800w 5600w/2800w
Maximum PV input
voltage
550V 550V 550V
MPPT Range 155-500V 188-500V 200-500V
Minimum input /
startup voltage
100V/150V 100V/150V 100V/150V
Maximum input
current for each
MPPT
13A/13A
Maximum power for
each string
16.5A/16.5A
MPPT path 2 2 2
AC output
Rated power 3680w 4600w 5000w
Maximum power 3680VA 4600VA 5000VA
Output voltage range 180V-280V 180V-280V 180V-280V
Output frequency
range
+/-5Hz +/-5Hz +/-5Hz
Rated frequency 50Hz/60Hz/230V 50Hz/60Hz/230V 50Hz/60Hz/230V
Maximum output 16A 20A 22A
