KStar KSH-3.68k-48 User Manual

28
Press UP/DOWN button to move
corresponding options;
Press Enter to enter the selected menu;
Press ESC button to return to setting
interface (refer to 8.2). Options include
reactive compensation mode, grid power,
discharge/charge power, low/high grid
power, low/high grid voltage and low/high
grid frequency (refer to 1~8).
Reactive mode①
Interface Description
Press UP/DOWN button to move
corresponding options;
Press Enter to confirm the input and enter
power factor setting interface;
(select 2, press Enter to confirm input and
enter reactive power interface)
Press ESC button to cancel the input and
return to operation parameters interface.
Power factor setting
Interface Description
Press UP/DOWN to increase or decrease
the input figure;
Press ENTER button to confirm or ESC
button to cancel the input and return to
working interface;
The input value should range between
L0.80 and L0.99 or C0.8 and C1.00.
Reactive Power
Interface Description
Press UP/DOWN button to adjustthe input
figure;
Press ENTER button to confirm or ESC
button to cancel the input and return to
working interface;
The input value should range between
-60% and +60%, which varies with the
--RUN SETTING--
→ 1：REACT POWER
2：GRID POWER
3：DISC POWER
4：CHAG POWER
5：VAC-MIN
6：VAC-MAX
7：FAC-MIN
8：FAC-MAX
--REACT MODE--
→1：POWER FACTOR
2：REACT POWER
3：QU WAVE
--POWER FACTOR--
INPUT: C1.00
Value range
(L1.00~C1.00)
--REACT POWER-
INPUT: +60%
Val ue ra n g e
(-60%~+60%)
