23
This interface is used for various
information inquiry options.
Press UP/DOWN button to move the
corresponding options.
Press ENTER to enter the selected menu.
Press ESC button to return to the user
interface(refer to 8.1.16)
There are 13 options in total, including
system mode, battery parameters, grid
standard, operation parameters, 485
address, 485 baud rate, language display,
LCD backlight, date/time, clear history,
password setting and maintenance, and
factory setting.
8.2.1 System setting
Interface Description
This interface is used to access system
information.
Press UP/DOWN button to move
corresponding options.
Press ENTER to enter the selected menu.
Press ESC button to return to the setting
interface.( refer to 8.3.1)
There are 6 options in total, including
working mode, backup enable, mandatory
charging of mains, program-controlled
enable, boot delay time, PV input type.
（
see from ① to ⑥
）
① Working mode
Interface Description
This interface is used to opt for the
working mode.
After selecting the three modes, the restart
interface will be entered.
Press ESC button to return to setting
interface.( refer to 8.2.1)
After completing the setup of peak load shifting mode, the time for charging and discharging also
needs to be set.
--SETUP--
→
1：SYS SETTING
2：BAT SETTING
3：GRID STD
4：RUN SETTING
5：485 ADDRESS
6：BAUD RATE
7：LANGUAGE
8：BACKLIGHT
9：DATE/TIME
10：CLEAR REC
11：PAS S WORD
12：MAINTENANCE
13：FCTRY RESET
--SYS SETTING--
→1:WORK MODE
2: EPS ENABLE
3: GRID CHARGE
4: REMOTE CTRL
5:START DELAY
6: PV INPUT
--WORKE MODE --
1:SELF COMSUME
