-31-
SNMP Trap SNMP trap function configuration
Disable - the device is disable to send SNMP trap messages.
Enable - the device is enable to send SNMP trap messages.
Community Name Set community string to be bound with trap packets
Trap IP Address Set IP address of the SNMP trap host
802.1Q Control 802.1Q Control function main configuration
Disable - all packets are allowed to pass with no 802.1Q control.
Enable - 802.1Q control mechanism is activated for the conversion.
QoS Control Enable / disable QoS Control function main configuration
Disable - Packet priority classification function is disabled.
Enable - Packet priority classification function is enabled.
Jumbo Mode Enable / disable Jumbo mode to support jumbo packets
Disable - support maximum packet size up to 1526 bytes
Enable - support maximum packet size up to 9600 bytes
Link fault pass through Enable / disable link fault pass through function
Remote TP auto report Enable / disable remote TP port link status function
[Apply] Click to apply the configuration change
[Refresh] Click to refresh current configuration
Note: It is suggested to give each device unit a system name as an alternative unique
identification beside IP address.
