-34-
Port Configuration Function
Port TP - Twisted-Pair copper port
FX - Fiber port
Link Port link status
Speed and duplex status with green background - port is link on
Down with red background - port is link down
Mode Select port operating mode
Disabled - disable the port operation
TP Mode Auto-negotiation Speed capability Duplex capability
Disable Disable port operation
Auto Enable 10, 100, 1000M Full, Half
10 Half Disable 10M Half
10 Full Disable 10M Full
100 Half Disable 100M Half
100 Full Disable 100M Full
1000 Full Enable 1000M Full
FX Mode Auto-negotiation Speed capability Duplex capability
Disable Disable port operation
1000 Full Enable 1000M Full
Force 1000 Full Disable 1000M Full
Flow Control Set port flow control function
V - set to enable 802.3x pause flow control for ingress and egress
802.1Q Control Function
Ingress Drop Disable - disable port ingress drop and admit all packet types
Untag Only - Drop both untagged and priority-tagged packets
Tag Only - Drop VLAN-tagged packets (VID<>0)
Ingress Keep Tag Tag is removed from the received packet if it exists.
Enable - set to activate tag removal for VLAN-tagged packets
Disable - set to disable tag removal function
Egress Insert Tag Tag is inserted into the outgoing packet in egress operation.
Enable - set to activate tagging
Disable - set to disable tagging function
Default Tag - VID Port VID, VID for Ingress Default Tag
1 ~ 4095 - decimal 12-bit VID value
Default Tag - CFI CFI for Ingress Default Tag
0, 1 - 1-bit CFI value
Default Tag -Priority User priority for Ingress Default Tag
0 ~ 7 - decimal 3-bit value
[802.1Q Filtering] Click to set VID filtering table
To Next Page
