-9-
LED Indicators
PWR Power status
LTP Local or remote TP indication on TP LEDs
LBT Loopback test in-progress LED
LBR Loopback test result LED
FXLNK Fiber port link and activity status
TP1G Twisted-pair copper port 1000Mbps and link status
TP100 Twisted-pair copper port 100Mbps and link status
TP10 Twisted-pair copper port 10Mbps and link status
TPFDX Twisted-pair copper port duplex status
Configuration DIP Switches
SW1-SW3 Twisted-pair copper port configuration
SW4 Flow control setting
SW5 Remote Twisted-pair copper port monitoring
SW6 Link fault pass through function setting
Center Interface
Interface For center chassis mounting
Connector FutureBus
Basic Functions
MAC Addresses Support up to 8K
Forwarding technology Store and forward
Maximum packet length Jumbo frame support up to 9600 bytes
Flow control IEEE 802.3x pause frame base for full duplex operation
Back pressure for half duplex operation
DC Power Input
Interfaces DC Jack ( -D 6.3mm / + D 2.0mm)
Operating Input Voltages +5 ~ +12VDC(+/-5%)
Power consumption 2.5W max. @7.5V
Mechanical
Dimension (base) 108 x 72.5 x 23 mm
Housing Enclosed metal with no fan
Mounting Desktop mounting, wall mounting, optional Rin-rail mounting
