TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 103

Remaining frame bolts M5 5 Nm (3.7 lbf ft) –

Screw, brake fluid reservoir of rear

brake

M5 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, brake line holder M5 5 Nm (3.7 lbf ft) –

Screw, chain guard M5 5 Nm (3.7 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, fuel tank cover M5 3 Nm (2.2 lbf ft) –

Screw, fuel tank guard M5x17 3 Nm (2.2 lbf ft) –

Screw, steering damper fixing bracket M5 5 Nm (3.7 lbf ft)

Loctite

243™

Bolt, foot brake lever stub M6 10 Nm (7.4 lbf ft)

Loctite

243™

Remaining chassis nuts M6 15 Nm (11.1 lbf ft) –

Remaining chassis screws M6 10 Nm (7.4 lbf ft) –

Screw for wheel speed sensor bracket M6 3 Nm (2.2 lbf ft)

Loctite

243™

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, foot brake lever M6 15 Nm (11.1 lbf ft)

Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, shift lever stub M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift rod M6 12 Nm (8.9 lbf ft)

Loctite

243™

Screw, shift shaft deflector on chain

securing guide

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift shaft deflector on shift

shaft

M6 18 Nm (13.3 lbf ft)

Loctite

243™

Fork end pinch bolts M8 15 Nm (11.1 lbf ft) –

Nut, forked bracket on foot brake lever M8 30 Nm (22.1 lbf ft)

Loctite

243™

Remaining chassis nuts M8 30 Nm (22.1 lbf ft) –

Remaining chassis screws M8 25 Nm (18.4 lbf ft) –

Screw for lifting gear support, rear M8 18 Nm (13.3 lbf ft)

Loctite

243™

Screw of rear brake caliper M8 22 Nm (16.2 lbf ft)

Loctite

243™

Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, clamp, eccentric shaft of

deflector

M8 18 Nm (13.3 lbf ft) –

Screw, front brake disc M8 30 Nm (22.1 lbf ft)

Loctite

243™

Screw, front footrest bracket M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, handlebar stub M8 20 Nm (14.8 lbf ft) –

Screw, rear brake disc M8 30 Nm (22.1 lbf ft)

Loctite

243™

Screw, shift lever M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, steering damper clamp on con-

sole

M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, steering damper fixing bracket

on triple clamp

M8 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, steering stem M8 20 Nm (14.8 lbf ft) –

Screw, subframe M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –

Remaining chassis nuts M10 50 Nm (36.9 lbf ft) –

Remaining chassis screws M10 45 Nm (33.2 lbf ft) –

Screw, connecting lever, shock

absorber deflector

M10 45 Nm (33.2 lbf ft)

Loctite

243™

Screw, engine bearer M10 45 Nm (33.2 lbf ft) –

Screw, shock absorber M10 45 Nm (33.2 lbf ft)

Loctite

243™

Rear sprocket bolt M10x1.25 50 Nm (36.9 lbf ft)

Loctite

243™

Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft)

Loctite

243™

Nut of bell crank on frame M14x1.5 100 Nm (73.8 lbf ft) –

Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased
