WHEELS, TIRES 14
153
F00745-11
–
Remove screw
2
and pull wheel speed sensor
3
out of the
hole.
–
Remove nut
4
and washer.
–
Take off chain adjuster
5
.
–
Holding the rear wheel, withdraw wheel spindle
6
with the
washer and chain adjuster
5
.
– Push the rear wheel forward as far as possible and take the
chain off the rear sprocket.
– Push chain guard to the side.
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Pull the rear wheel back and take it out of the link fork.
Info
Do not operate the foot brake lever when the rear wheel
is removed.
