KTM 125 DUKE 2021 - Engine Tightening Torques

22 TECHNICAL DATA
220
22.2 Engine tightening torques
Oil nozzle M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, engine vent plate M5 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, retaining bracket M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket, stator
cable
M5 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, stator M5 8 Nm (5.9 lbf ft)
Loctite
®
243™
Cylinder head screw M6 12 Nm (8.9 lbf ft)
Nut, water pump impeller M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw plug, water pump drain hole M6 10 Nm (7.4 lbf ft)
Screw, alternator cover M6 12 Nm (8.9 lbf ft)
Screw, bearing retainer M6 12 Nm (8.9 lbf ft)
Loctite
®
243™
Screw, camshaft bearing bridge M6 10 Nm (7.4 lbf ft)
Screw, chain securing guide M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch cable retaining
bracket
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
