DASH 7
53
Info
When all the bars light up, the ENGINE TEMP HIGH warning
also appears.
If the cooling system overheats, the maximum engine
speed is limited.
Possible states
• The engine is cold – Up to three bars light up.
• Engine warm – Four to five bars light up.
• Engine hot – Six to eight bars light up.
• Engine very hot – All eight bars light up red.
7.12 Fuel level display
402807-10
The fuel tank contents are shown in area
1
of the display.
The fuel level indicator consists of bars. The more bars are lit, the
more fuel is in the fuel tank.
