23 TECHNICAL DATA 176
Front 300 mm (11.81 in)
Rear 230 mm (9.06 in)
Brake discs - wear limit
Front 4.5 mm (0.177 in)
Rear 3.6 mm (0.142 in)
Tire air pressure, solo
Front 2.0 bar (29 psi)
Rear 2.0 bar (29 psi)
Tire air pressure with passenger/full payload
Front 2.0 bar (29 psi)
Rear 2.2 bar (32 psi)
Secondary ratio 15:45
Chain 5/8 x 1/4” (520) O‑ring
Steering head angle 66.5°
Wheelbase 1,340±15 mm (52.76±0.59 in)
Seat height, unloaded 820 mm (32.28 in)
Ground clearance, unloaded 178 mm (7.01 in)
Weight without fuel, approx. 152.5 kg (336.2 lb.)
Maximum permissible front axle load 125 kg (276 lb.)
Maximum permissible rear axle load 210 kg (463 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
