23 TECHNICAL DATA 182

Screw, voltage regulator holder M6 11 Nm (8.1 lbf ft) –

Screw, wheel speed sensor holder M6 9 Nm (6.6 lbf ft) Loctite

243™

Screw, windshield M6 9 Nm (6.6 lbf ft) –

Nut, rear sprocket screw M8 27 Nm (19.9 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, chain guard M8 11 Nm (8.1 lbf ft) –

Screw, engine bearer on frame M8 24 Nm (17.7 lbf ft) –

Screw, foot brake lever M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, front wheel spindle M8 20 Nm (14.8 lbf ft) –

Screw, fuel tank attachment, rear, on

frame

M8 16 Nm (11.8 lbf ft) –

Screw, horn M8 7 Nm (5.2 lbf ft) –

Screw, main silencer M8 23 Nm (17 lbf ft) –

Screw, passenger footrest bracket M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, shift lever M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, top triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8x1 30 Nm (22.1 lbf ft) Loctite

204™

Fitting, engine mounting bracket M10 50 Nm (36.9 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Banjo bolt, brake line M10x1 24 Nm (17.7 lbf ft) –

Fitting, shock absorber, bottom M10x1.25 50 Nm (36.9 lbf ft) –
