COOLING SYSTEM 141
301838-11
– Remove the radiator cap 1.
– Fill the coolant into the radiator.
Coolant 1.50 l (1.59 qt.) Coolant ( p. 182)
Coolant (mixed ready to use) ( p. 182)
301840-10
– Open screw 2 to bleed the radiator. Tighten the screw when coolant emerges from the
opening.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
301839-10
– Add coolant to level A above the radiator fins.
Guideline
10 mm (0.39 in)
– Mount the radiator cap.
– Install the front trim. ( p. 77)
– Make a short test ride.
– Check the coolant level. ( p. 138)
