TUNING THE ENGINE 148
15.8Changing the ignition curve
– Remove the front trim. ( p. 75)
Changing the ignition curve from Performance to Soft.
– Disconnect plug-in connector 1. (Figure 301829-10 p. 147)
Soft – The plug-in connector is disconnected for better driveability. ( p. 147)
Changing the ignition curve from Soft to Performance.
– Connect the plug-in connector 1. (Figure 301829-10 p. 147)
Performance – The plug-in connector is connected to achieve better performance. ( p. 147)
– Install the front trim. ( p. 77)
15.9Checking the basic setting of the shift lever
00
0
AA
400692-10
– Sit on the vehicle in the riding position and determine the distance A between the
upper edge of your boot and the shift lever.
Distance between shift lever and upper
edge of boot
10… 20 mm (0.39… 0.79 in)
» If the distance does not meet specifications:
–
Adjust the basic position of the shift lever. x ( p. 149)
