TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 181
Screw, footrest M10 45 Nm (33.2 lbf ft) –
Screw, front shock absorber M10 45 Nm (33.2 lbf ft) –
Screw, steering column at bottom of
steering lever
M10 25 Nm (18.4 lbf ft) –
Nut, ball head, A-arm top M10x1.25 35 Nm (25.8 lbf ft) –
Nut, rear sprocket screw M10x1.25 45 Nm (33.2 lbf ft)
Loctite
®
243™
Nut, tie rod end M10x1.25 45 Nm (33.2 lbf ft) –
Wheel nut M10x1.25 45 Nm (33.2 lbf ft) –
Nut, front wheel hub M12 70 Nm (51.6 lbf ft) –
Screw, rear bottom shock absorber M12 70 Nm (51.6 lbf ft) –
Screw, rear top shock absorber M12 60 Nm (44.3 lbf ft) –
Lock nut, tie rod, inside M12LHx1.25 20 Nm (14.8 lbf ft) –
Lock nut, tie rod, outside M12x1.25 20 Nm (14.8 lbf ft) –
Nut, A-arm top M12x1.25 30 Nm (22.1 lbf ft) –
Nut, ball head, A-arm bottom M12x1.5 40 Nm (29.5 lbf ft) –
Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –
Nut, rear wheel hub M18x1.5 130 Nm (95.9 lbf ft) –
Screw, steering column, bottom M20x1.5 40 Nm (29.5 lbf ft) –
Screw, steering column, top M20x1.5 25 Nm (18.4 lbf ft) –
Clamping nut, rear axle 2"-10UNS-2B-LH 25 Nm (18.4 lbf ft) Only applies when using:
Open-end wrench
attachment, 46 mm
(83019010461)
