TUNING THE CHASSIS 62
800064-10
– Tighten the spring packet by turning adjusting ring 2 to measurement A.
Guideline
Spring preload
Comfort 3 mm (0.12 in)
Standard 5 mm (0.2 in)
Sport 8 mm (0.31 in)
Info
Spring preload A is the difference in length between the spring pack when it is
unloaded and when it is installed.
The spring pack should never be installed loosely (without preload). The stan-
dard setting is the lowest permissible spring preload. Therefore, you can only
increase the spring preload.
If you increase the spring preload, you should also slightly increase the rebound
damping.
The left and right shock absorbers should have the same settings.
– Tighten the retaining ring and adjusting ring.
– Remove the vehicle from the lifting gear. ( p. 67)
