MAINTENANCE WORK ON THE CHASSIS 95
B00464-10
– Pull on the lower part of the chain with the specified weight A.
Guideline
Chain-wear measuring weight 10… 15 kg (22… 33 lb.)
– Measure the distance B of 18 chain links in the upper chain section.
Info
Chain wear is not always even, so you should repeat this measurement at differ-
ent chain positions.
Maximum distance B at the longest
chain section
272 mm (10.71 in)
» If the distance B is greater than the specified measurement:
–
Replace the chain. x
Info
When you replace the chain, you should also change the rear sprocket
and engine sprocket.
New chains wear out faster on old, worn sprockets.
