OPERATION INSTRUMENTS »
11
Tachometer
The tachometer [3] shows the engine speed in revolutions per minute. Do not run the engine
beyond the orange mark at 7800 rpm.
The speed limiter will set in at 8600 rpm, drastically reducing the engine power above this
rotational speed.
Cooling liquid temperature display
The temperature display [1] is shown in 12 bars. The more bars that light up, the hotter the
cooling liquid. When the upper bar lights up 115°C (239°F), all of the bars will start to blink
and the red warning lamp [2] will light up.
Possible causes for an increase in temperature, causing the red warning light for the cool-
ing liquid temperature to light up:
– Driving too slowly and driving with a heavy load at high air temperatures
– Not enough cooling liquid in the system
– The ventilator on the left radiator is not running
– Improper use of the clutch when driving slowly
