TECHNICAL SPECIFICATIONS – CHASSIS »
77
CHASSIS 690 SUPERMOTO 2007 690 SUPERMOTO PRESTIGE 2007
Battery maintenance-free battery 12V / 8.6 Ah
Gear ratio – rear wheel 17:41 (17:42)
Chain 5/8 x 1/4” X-ring
Steering head angle 63.5°
Wheel base 1472 ± 15 mm (57.95 ± 0.6 in)
Seat height, unloaded 880 mm (34.65 in)
Ground clearance, unloaded 245 mm (9.65 in)
Dry weight 154 kg (339.5 lbs)
Max. axle load front 150 kg (330.7 lbs)
Max. axle load rear 200 kg (440.9 lbs)
Max. total load 350 kg (771.6 lbs)
FORK 690 SUPERMOTO 690 SUPERMOTO PRESTIGE
Type 14.18.7C.07 WP Suspension 14.18.7C.08 WP Suspension
Spring 5.2 - 430 5.2 - 430
Air chamber length 100 mm (39.37 in) 100 mm (39.37 in)
Fork oil SAE 2.5 SAE 2.5
SHOCK ABSORBER 690 SUPERMOTO 690 SUPERMOTO PRESTIGE
Type 15.18.9C.07 WP Suspension 15.18.7C.08 WP Suspension
Spring 65 - 230 65 - 230
Spring preload 12 mm (0.472 in) 12 mm(0.472 in)
