KTM 690 LC4 - Page 88

CONSUMER INFORMATION FOR USA ONLY »
87
750.01.099.000
FORK SHOCK
SETTING
Compression (clicks) Rebound (clicks) Compression Low Speed (clicks) Compression High Speed (turns) Rebound (clicks) Spring preload (mm)
Comfort - 20 - - 20 12
BASIC SETTING - 15 - - 15 12
Sport - 10 - - 10 12
Max. payload - 10 - - 10 12
[8] Suspension setting[7] Before you go for the first ride
[5] Vehicle emission
[2] Type label CAN
[6] Noise emission
[1] EAVP
5 mm
5mm
750.04.099.000
[4] Chain tension
[3] Type label USA
