23 TECHNICAL DATA
120
Fuel tank capacity, approx. 14 l (3.7 US gal) Super unleaded (ROZ 95)
( p. 128)
23.4 Chassis
Frame Lattice frame made of chrome molybdenum steel tub-
ing, powder-coated
Fork WP Suspension Up Side Down 4357
Shock absorber WP Suspension 4614
Suspension travel
front 113 mm (4.45 in)
rear 123 mm (4.84 in)
Brake system
front Double disc brake with radially mounted four-piston
brake calipers, floating brake discs
rear Disc brake with single-piston brake caliper, floating
Brake discs - diameter
front 300 mm (11.81 in)
rear 240 mm (9.45 in)
Brake discs - wear limit
front 4.5 mm (0.177 in)
rear 4.5 mm (0.177 in)
Tire pressure when solo
front 2.3 bar (33 psi)
rear 2.6 bar (38 psi)
Tire pressure with passenger / full payload
front 2.3 bar (33 psi)
rear 2.6 bar (38 psi)
Secondary drive ratio 16:41
Chain 5/8 x 1/4” (520) X‑ring
Steering head angle 66°
Wheelbase 1,475 ± 15 mm (58.07 ± 0.59 in)
Seat height unloaded 800 mm (31.5 in)
Ground clearance unloaded 161 mm (6.34 in)
Weight without fuel, approx. 174.6 kg (384.9 lb.)
Maximum permissible front axle load 160 kg (353 lb.)
Maximum permissible rear axle load 270 kg (595 lb.)
Maximum permissible overall weight 430 kg (948 lb.)
