TECHNICAL DATA 23
123
Screw, foot brake lever stub M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fuel tank bracket M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fuel tank spoiler M6 3 Nm (2.2 lbf ft)
Screw, ground wire on frame M6 6 Nm (4.4 lbf ft)
Screw, ground wire to starter motor M6 10 Nm (7.4 lbf ft)
Screw, ignition lock (tamper-proof
screw)
M6 22 Nm (16.2 lbf ft)
Loctite
®
243™
Screw, license plate holder M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, magnetic holder on side
stand
M6 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, manifold clamp M6 8 Nm (5.9 lbf ft)
Screw, radiator bracket, bottom M6 5 Nm (3.7 lbf ft)
Screw, seat lock M6 8 Nm (5.9 lbf ft)
Loctite
®
222™
Screw, shift lever stub M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift rod M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift shaft deflector on shift
shaft
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, wheel speed sensor M6 6 Nm (4.4 lbf ft)
Nut, manifold on cylinder head M8 Tighten the nuts evenly. Do not
bend the metal.
20 Nm (14.8 lbf ft)
Copper paste
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Pin, rear brake caliper M8 22 Nm (16.2 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, cross member M8x18 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, cross member in rear M8x35 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, engine fixing arm linkage
bracket
M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, foot brake lever M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, footrest bracket, rear M8x25 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, footrest bracket, rear M8x40 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake disc M8 28 Nm (20.7 lbf ft)
Loctite
®
2701™
