14 ELECTRICAL SYSTEM
104
F03753-10
Main work
–
Take off protection cap
1
.
–
Remove the faulty fuse
2
.
Info
A faulty fuse has a burned-out fuse wire
A
.
– Insert the new fuse for the fuel pump.
Fuse (58011109105) ( p. 132)
– Check that the electrical system is functioning properly.
– Attach the protection cap.
Finishing work
– Mount the seat. ( p. 62)
14.6 Diagnostics connector
A01108-10
Diagnostics connector
1
is located under the seat.
