SERVICE WORK ON THE CHASSIS 11
57
11.13 Lubricating the steering head bearing
H02387-01
– Remove the lower triple clamp. ( p. 53)
– Install the lower triple clamp. ( p. 53)
Info
The steering head bearing is cleaned and lubricated in
the course of removal and installation of the lower triple
clamp.
11.14 Removing the start number plate
S05336-10
–
Remove screw
1
.
– Unhook the start number plate from the brake line and remove
it.
11.15 Installing the start number plate
S05337-10
–
Position the brake line in holders
A
on the start number
plate.
–
Position the start number plate. Mount and tighten screw
1
.
The holding lugs engage in the fender.
11.16 Removing front fender
Preparatory work
– Remove the start number plate. ( p. 57)
