22 TECHNICAL DATA
134
22.7.3 XC‑F US
Fork article number A460C177W406000
Fork WP XACT 5448
Compression damping
Comfort 17 clicks
Standard 12 clicks
Sport 7 clicks
Rebound damping
Comfort 23 clicks
Standard 18 clicks
Sport 13 clicks
Air pressure 9.9 bar (144 psi)
Fork length 950 mm (37.4 in)
Oil capacity external mechanism
right
230
+ 10
− 50
ml (7.78
+ 0.34
− 1.69
fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 140)
Oil capacity external mechanism
left
230
+ 10
− 50
ml (7.78
+ 0.34
− 1.69
fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 140)
Oil capacity, right cartridge 380 ml (12.85 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 140)
Grease capacity, left cartridge 5 g (0.18 oz) Special grease (00062010053)
( p. 142)
22.8 Shock absorber
22.8.1 SX‑F EU/AR
Shock absorber article number A460C407W408000
Shock absorber WP XACT 5750
Lowspeed compression damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Highspeed compression damping
Comfort 2 turns
Standard 1.5 turns
Sport 1 turn
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 8 mm (0.31 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 42 N/mm (240 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 45 N/mm (257 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 48 N/mm (274 lb/in)
Spring length 240 mm (9.45 in)
Gas pressure 10 bar (145 psi)
