4 VIEW OF VEHICLE

4.1 View of vehicle, front left (example)

S05319-01

Hand brake lever ( p. 14)

Clutch lever ( p. 14)

Fuel tank filler cap

Air filter box cover

Cold start button ( p. 18)

Shift lever ( p. 19)
