13 SERVICE WORK ON THE CHASSIS
128
V00602-10
– Push the chain up in the area behind the chain guide.
– Check the chain sliding guard for wear.
» If the chain sliding guard has lost material due to wear to
the extent that, in area
C
, the drilled hole of screw
1
is
visible from above:
– Change the chain sliding guard.
– Check that the chain sliding guard is firmly seated.
» If the chain sliding guard is loose:
– Tighten screws on the chain sliding guard.
Finishing work
– Remove the rear of the motorcycle from the lifting gear.
( p. 110)
13.15 Removing the battery cover
Preparatory work
– Remove the front rider's seat. ( p. 116)
