15 WHEELS, TIRES
158
15.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 110)
– Lift the motorcycle with the front lifting gear. ( p. 111)
K00717-10
Main work
–
Remove screws
1
, take off reflector and push the fender to
the side.
–
Remove screw
2
and pull wheel speed sensor
3
out of the
hole.
–
Loosen screw
4
by several rotations.
–
Loosen screws
5
.
–
Press on screw
4
to push the wheel spindle out of the axle
clamp.
–
Remove screw
4
.
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Hold the front wheel and remove the wheel spindle. Take the
front wheel out of the fork.
