TECHNICAL DATA 23
237
rear 230 mm (9.06 in)
Brake discs - wear limit
front 4.0 mm (0.157 in)
rear 3.6 mm (0.142 in)
Tire pressure when solo
front 2.0 bar (29 psi)
rear 2.0 bar (29 psi)
Tire pressure with passenger / full payload
front 2.0 bar (29 psi)
rear 2.1 bar (30 psi)
Secondary ratio 15:45
Chain 5/8 x 1/4” (520) O‑ring
Steering head angle 66.5°
Wheelbase 1,340 ± 15 mm (52.76 ± 0.59 in)
Seat height, unloaded 820 mm (32.28 in)
Ground clearance, unloaded 148 mm (5.83 in)
Weight without fuel, approx. 159 kg (351 lb.)
Maximum permissible front axle load 125 kg (276 lb.)
Maximum permissible rear axle load 210 kg (463 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
