TECHNICAL DATA 23
241
Screw, retaining plate on license
plate holder
M5 4 Nm (3 lbf ft)
Screw, side stand sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, tail end lower part M5 4 Nm (3 lbf ft)
ABS fitting M6 7 Nm (5.2 lbf ft)
Loctite
®
243™
Battery compartment cover lock M6 6 Nm (4.4 lbf ft)
Nut, license plate holder M6 7 Nm (5.2 lbf ft)
Nut, radiator M6 5 Nm (3.7 lbf ft)
Nut, tail light M6 7 Nm (5.2 lbf ft)
Remaining nuts, chassis M6 15 Nm (11.1 lbf ft)
Remaining screws, chassis M6 9 Nm (6.6 lbf ft)
Screw, air filter box cover M6 6 Nm (4.4 lbf ft)
Screw, air filter box, on frame M6 6 Nm (4.4 lbf ft)
Screw, battery compartment M6 6 Nm (4.4 lbf ft)
Screw, brake fluid reservoir, rear
brake
M6 8 Nm (5.9 lbf ft)
Screw, brake hose clamp M6 6 Nm (4.4 lbf ft)
Screw, brake line guide on bottom
triple clamp
M6 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, chain guard M6 6 Nm (4.4 lbf ft)
