S-39
V3300-E2B, V3300-T-E2B, WSM
DIESEL ENGINE
Governor Lever
1. Remove the speed control lever (1) and the return spring (2).
2. Remove the governor lever assembly (4) from the governor
housing.
3. Remove the start spring (5) and the stop spring (3).
W1142375
Stop Lever
1. Remove the stop lever (1) and the return spring (2).
2. Remove the stop lever shaft (3).
W1143531
(1) Speed Control Lever
(2) Return Spring
(3) Stop Spring
(4) Governor Lever Assembly
(5) Start Spring
(1) Stop Lever
(2) Return Spring
(3) Stop Lever Shaft
