Mower conditioner
28
FC302RG - FC352RG
Putting into service
KN271BGB C
Preparing the tractor
The machine adapts to tractors fitted with a 2-point hitch
coupler category 2 or 3.
The tractor PTO stub must rotate at a speed of 540 or
1000 min
-1
.
The tractor must be equipped with:
- 1 double acting hydraulic outlet.
- 1 single acting hydraulic outlet.
Hitch pin parallelism
Adjust tractor lift rods so that hitch pins are parallel to the
ground.
Check that the tractor's authorized gross
weight as well as its lift capacity and
maximum weight per axle are not exceeded:
See section:
- Safety / Safety instructions / Precautions
when driving on public roads.
The tractor must be fitted with lower link
stabilizers.
