Putting into service
Mower conditioner
FC302RG - FC352RG
37
KN271BGB C
Adjusting the machine
Lateral adjustment of the lower links.
- Balance the play on either sides of the lift linkage and
lock lower link stabilizers.
Frame height
- Lower the tractor lift linkage to obtain measure (H) of
500 to 550 mm (1’7’’ - 1’9’’) between the hitch pins
and the ground.
-
When optional equipment is used, follow specific
procedures mentioned in the related section:
Chain stroke limiter.
