Mower conditioner
50
FC302RG - FC352RG
Instructions for work
KN271BGB C
Conditioning intensity
Conditioning intensity is determined by the pressure
exerted by the two rollers.
The pressure can be adjusted from 0 to 5 daN/cm
(0à25lbf/in).
- Lift up the front guard.
- Loosen counter nut (1).
- Tighten nut (2) to increase the conditioning intensity.
- Loosen nut (2) to reduce the conditioning intensity.
- Tighten counter nut (1).
Before adjusting, maintaining or repairing
the machine, turn off ignition key and wait
until all moving parts have come to a
complete stop.
The pressure is factory set at
2.5 daN/cm (12.5 lbf/in).
