Mower conditioner
54
FC302RG - FC352RG
Instructions for work
KN271BGB C
To form a swath over the whole conditioning
width:
FC302RG (a):
- Loosen 2 handles (1) (1 on each side).
- Lower the inner swath shield using
control (2)
- Tighten 2 handles (1).
FC352RG (b):
- Lower the inner swath shield using
control (1).
1
2
a
1
b
