KUHN HRB202 - Page 86

HRB202-202S-252D-302D
86
9. - Optional equipment
KN136JGB_D
Power harrow
- Loosen screw (3).
- Remove bolt (2) and nut (1).
- Place hook (4) in the required position.
- Tighten screw (3).
- Reinstall bolt (2) and nut (1):
• Torque (2) (3): 42 daNm (309 lbf ft).
- Adjust both sides to the same setting.

Coupling the machine
- Remove pin (1).
- Remove pin (2).
- Unlock the rear attachment hooks (3).
- Proceed the same way on the other side.
- Disconnect the hydraulic ground pressure control
system to fully lower the rear attachment lift (1).
3
2
1
4
2
1
3
4
1
2
3
1
