KUHN HRB202 - Page 87

9. - Optional equipment
HRB202-202S-252D-302D
87
KN136JGB_D
Power harrow
- Lower the tractor three-point linkage.
- Lower the rear attachment lift.
- Place the lower links as close as possible under
the hitch pins.
- Raise the rear attachment lift.
- Attach lower links to the hitch pins on the inside of
the yokes.
- Lock the rear attachment hooks (1).
- Insert pin (2).
- Fit pin (3).
- Attach top link.
- Proceed the same way on the other side.
- Refer to the operator's manual of the
machine.
- Connnect the hydraulic ground pressure control
device (1).
- Lock tractor lower link stabilisers.
2
1
3
4
3
2
1
1
1
