Control Functions of Mechanism
20
1. Left blinker: Direction button for left or right turn,
indicator light will flash when turned on; press middle
button to turn off.
2. Fuel gauge: The fuel gauge is divided into five
sections.
3. High beam: When this indicator lit, the headlight
is in the high beam position.
4. The Oil Pressure Warning Indicator: The Oil
Pressure Warning Indicator lights up when KEYLESS
Main Switch is activated.
The Oil Pressure Warning Indicator will go off when
the engine is started.
The Oil Pressure Warning Indicator will light up if the
oil pressure is lower than normal action when the
engine rotates. This denotes a system anomaly; you
need to go to a KYMCO dealer for a check-up.
5. Engine inspection indicator: After “KEY ON,” the
engine inspection indicator will illuminate and then
extinguish by itself after starting the engine. In this
case, it means the vehicle is under normal conditions.
If the indicator is persistently lit, it means there are
problems in the vehicle system. Please visit the
service station for inspection and maintenance.
6. Cruise control: This function is the settings for
cruise control, please refer to “Settings for Cruise
Control”.
7. Oil/belt service indicator: OIL → Oil change
indicator. When the vehicle reaches 5,000 km, the
services symbol on the right side of the dashboard will
stay lit, indicating that oil needs to be checked.
Belt→Belt Replacement Indicator. After running
20000km, the “services” symbol on the right of
Dashboard lights up constantly, indicating a CVT belt
replacement is required.
